3203 Turmeric
-
3203
sq/ft
-
4 Bed
-
3 Bath
-
2
House Construction Drawings
$1,620.32
Key Features
- Bedrooms: 4
- Baths: 3
- Garage Swing: Front Entry
- Stories: 2
Area
- House Area: 3203
- Total Area: 3959
Dimension
- Width: 58'-8"
- Depth: 61'-6"
- Height: 35'-1 1/2"
Exterior Wall
- Framing: 2x4
- Wall Finish: Stucco
Roof
- Primary pitch: 10:12
- Secondary Pitch: 8:12
House Interior
- Ceiling Height: 10'-0"
- Main living area ceiling height: 12'-0"
Description
Your Purchase includes an Architectural set in PDF format with the following contents:
C0- Revision Index, General Notes
A2- First Floor Plan
A3- Second Floor Plan
A4- Front & Rear Elevations
A5- Right & Left Elevations
A6- Roof Plan
E1- First Floor Electrical Plan
E2- Second Floor Electrical Plan
P1- First Floor Plumbing Plan
P2- Second Floor Plumbing Plan
F1- Foundation Plan
D1- Additional Details
D2- Additional Details
S1- First Floor Shear Wall Plan
S2- Second Floor Shear Wall Plan
S3- Shear Wall Details
R1- First Floor Ceiling Joist Plan
R2- First Floor Rafter Support
R3- Roof Plan Rafter Plan
R4- Framing Plan Details
R5- Framing Plan Details
Blueprints That You Get
