3150 Shack

  • plan-area 3150 sq/ft
  • plan-area 4 Bed
  • plan-area 4 Bath
  • plan-area 2

House Construction Drawings

$1,658.45



Key Features

  • Bedrooms: 4
  • Baths: 4
  • Garage Swing: Side Entry
  • Stories: 2

Area

  • House Area: 3150
  • Total Area: 4045

Dimension

  • Width: 83'-2 1/2"
  • Depth: 56'-11 1/2"
  • Height: 29'- 4 1/8"

Exterior Wall

  • Framing: 2x4
  • Wall Finish: Siding, Brick & Stone Veneer

Roof

  • Primary pitch: 9:12
  • Secondary Pitch: 10:12

House Interior

  • Ceiling Height: 9'-0"
  • Main living area ceiling height: 10'-0"

Description

Your Purchase includes an Architectural set in PDF format with the following contents:

C0- Revision Index, General Notes

A1- First Floor Plan

A2- Second Floor Plan

A3- Front & Rear Elevations

A4- Right & Left Elevations

A5- Roof Plan

I1- Int. Elevations

E1- First Floor Electrical Plan

E2- Second Floor Electrical Plan

P1- First Floor Plumbing Plan
