1792 Morgan
-
1792
sq/ft
-
3 Bed
-
2 Bath
-
1
House Construction Drawings
$1,058.21
Key Features
- Bedrooms: 3
- Baths: 2
- Garage Swing: Side Entry
- Stories: 1
Area
- House Area: 1792
- Total Area: 2581
Dimension
- Width: 62'-10 1/2"
- Depth: 46'-9 1/2"
- Height: 23'-9 1/2"
Exterior Wall
- Framing: 2x4
- Wall Finish: Brick Venner, Siding
Roof
- Primary pitch: 12:12
- Secondary Pitch: 8:12
House Interior
- Ceiling Height: 9'-0"
- Main living area ceiling height: 11'-0"
Description
Your Purchase includes an Architectural set in PDF format with the following contents:
C1- Revision Index, General Notes
A1- First Floor Plan
A2- Front & Rear Elevations
A3- Right & Left Elevations
A4- Roof Plan
E1- First Floor Electrical Plan
P1- Plumbing Plan
D1- Typical Details
D2- Typical Details
D3- Typical Details
F1- Foundation Plan
F2- Foundation Details
R1- First Floor Ceiling Joist Plan
R2- First Floor Rafter Support
R3- Roof Rafter Plan
R4- Framing Details
R5- Framing Details
R6- Framing Details
Blueprints That You Get
