1600 Pioneer

  • plan-area 1653 sq/ft
  • plan-area 3 Bed
  • plan-area 2 Bath
  • plan-area 1

House Construction Drawings

$867.15



Key Features

  • Bedrooms: 3
  • Baths: 2
  • Garage Swing: Front Entry
  • Stories: 1

Area

  • House Area: 1653
  • Total Area: 2115

Dimension

  • Width: 40'-0"
  • Depth: 58'-6"
  • Height: 22'-3 31/4"

Exterior Wall

  • Framing: 2x4
  • Wall Finish: Brick & Stone Veneer

Roof

  • Primary pitch: 8:12

House Interior

  • Ceiling Height: 9'-0"

Description

Your Purchase includes an Architectural set in PDF format with the following contents:

C1- Revision Index, General Notes

A2- First Floor Plan

A3- Floor Plan Options

A4- Front & Rear Elevations

A5- Right & Left Elevations

A6- Roof Plan

I1- Interior Elevations

D1- Typical Details

E1- Electrical Plan

E2- Electrical Plan (Options)

Reviews

There are no reviews yet.

Be the first to review “1600 Pioneer”

Your email address will not be published. Required fields are marked *

Blueprints That You Get

Lorem ipsum dolor sit amet consectetur adipisicing elit. A excepturi doloribus quasi vitae odio porro omnis repellendus libero iste sed neque quia, maiores atque ut laudantium inventore, id rerum error!
